Multiple-disc clutch in oil bath, mechanically operated
Gearbox
5 speed
Ratios
-
Primary drive
-
Final drive
Chain
Starting system
Electronic
Frame
Bridge-type steel section frame with bolted-on rear section
Front suspension
Telescopic fork, stanchion diameter 41 mm, fork stabiliser, 170 mm travel
Rear suspension
Box-section steel section dual swing arm, central spring strut action via lever system, spring pre-load hydraulically adjustable to continuously variable levels by means of handwheel, rebound damping adjustable, 165 mm travel
