1172 cc, water cooled, 4 - cylinders in line, 4-stroke
Bore x stroke (mm)
70.5 mm x 75 mm
Compression ratio
10.8:1
Valves
SOHC, 4 valves per cylinder
Fuel system
Electronic intake pipe injection
Ignition
BMW engine management, Motronic MA 2.4 with overrun fuel cut-off
Power
98 hp (73.1 kW) @ 6750 rpm
Torque
115 Nm (84.8 ft. lbs) @ 4750 rpm
Lubrication system
-
Clutch
Single-disc dry clutch, hydraulically operated
Gearbox
5 speed
Ratios
-
Primary drive
-
Final drive
Cardan
Starting system
Electronic
Frame
Bridge-type frame, die-cast aluminium, engine decoupled from vibrations through bearings
Front suspension
BMW Motorrad Telelever; stanchion diameter 35 mm, central strut, 102 mm travel
Rear suspension
Die-cast aluminium single-sided swing arm with BMW Motorrad Paralever; central spring strut, spring pre-load hydraulically adjustable to continuously variable levels by means of handwheel, 130 mm travel
