digital engine management: Bosch Motronic MA 2.4 with overrun fuel cut-off
Power
70 hp (52.2 kW) @ 7000 rpm
Torque
77 Nm (56.8 ft. lbs) @ 5500 rpm
Lubrication system
-
Clutch
Single-disc dry clutch, hydraulically operated
Gearbox
5 speed
Ratios
-
Primary drive
-
Final drive
Cardan
Starting system
Electronic
Frame
Three-section composite frame consisting of front and rear section, load bearing engine.
Front suspension
BMW Motorrad Telelever; stanchion diameter 35 mm, central strut, rebound damping adjustable, 120 mm travel
Rear suspension
Die-cast aluminium single-sided swinging arm with BMW Motorrad Paralever; central strut, spring pre-load adjustable to continuously variable levels by means of hydraulic handwheel, rebound damping adjustable, 135 mm travel
