Beta Alp 200 2007 motorcycles specifications

www.motorcyclesdetails.info

add to favorites

Year : 2007 , Category : Trial , Type : 199 cc, air cooled, single cylinder, 4-stroke , Bore x stroke (mm) : 66 mm x 58.2 mm

Details:

Beta Alp 200 2007 motorcycles specifications
read comments (-)	\|	add comments

Year

2007

Category

Trial

Type

199 cc, air cooled, single cylinder, 4-stroke

Bore x stroke (mm)

66 mm x 58.2 mm

Compression ratio

9.4:1

Valves

SOHC, 2 valves per cylinder

Fuel system

Mikuni BST 31 42AD

Ignition

Electronic

Power

15 hp (11.2 kW) @ 7750 rpm

Torque

Lubrication system

forced lubrication with pump

Clutch

Multiple disc clutch in oil bath

Gearbox

5 speed

Ratios

Primary drive

19/60

Final drive

Chain

Starting system

Electronic & Kick

Frame

steel double cradle frame

Front suspension

Hydraulic fork, 38 mm tubes, 170 mm travel

Rear suspension

single shock with adjustable spring, 180 mm travel

Rake / Traill

Wheels

Front whell

Rear whell

Front tyre

90/90-21

Back tyre

120/80-18

Front brakes

single 245 mm disc with 2-piston calipers

Rear brakes

single 220 mm disc with 1-piston calipers

Overall length

2150 mm (84.6 inches)

Overall width

820 mm (32.3 inches)

Overall height

1150 mm (45.3 inches)

Seat height

850 mm (33.5 inches)

Wheelbase

1350 mm (53.1 inches)

Ground clearance

298 mm (11.7 inches)

Fuel capacity - reserve

6.8 l (1.8 gallon US) - 1.5 l (0.4 gallon US)

Dry weight

101 kg (222.7 pounds)
