Bimota DB5S 2007 motorcycles specifications

www.motorcyclesdetails.info

add to favorites

Year : 2007 , Category : Sport , Type : 1079 cc, oil/air cooled, l-twin, 4-stroke , Bore x stroke (mm) : 98 mm x 71.5 mm ,

Details:

Bimota DB5S 2007 motorcycles specifications
read comments (-)	\|	add comments

Year

2007

Category

Sport

Type

1079 cc, oil/air cooled, l-twin, 4-stroke

Bore x stroke (mm)

98 mm x 71.5 mm

Compression ratio

10Â±0.5:1

Valves

Desmodromic, 2 valves per cylinder

Fuel system

Electronic Fuel injection, 45mm trottle body

Ignition

Power

95 hp (70.8 kW) @ 7000 rpm

Torque

102.96 Nm (75.9 ft. lbs) @ 5500 rpm

Lubrication system

With wet sump

Clutch

Dry multi-plate with hydraulic control

Gearbox

6 speed

Ratios

Primary drive

Final drive

Chain

Starting system

Electronic

Frame

25/20mm tubular chrome molybdenum steel trellis with lateral plates in aircraft alloy

Front suspension

50mm UD Marzocchi TIN Coated Fork, fully adjustable (Preload - External Hydraulic Device, Compression, Rebound, 120 mm travel

Rear suspension

Extreme Tech monoshock, fully adjustable (Preload - External Hydraulic Device, Compression, Rebound), 120 mm travel

Rake / Traill

Wheels

Alluminium Alloy

Front whell

Rear whell

Front tyre

120/60-17

Back tyre

180/55-17

Front brakes

dual 320 mm discs with radial-mounted 4-piston calipers

Rear brakes

single 220 mm disc with 2-piston calipers

Overall length

Overall width

Overall height

Seat height

810 mm (31.9 inches)

Wheelbase

1425 mm (56.1 inches)

Ground clearance

Fuel capacity - reserve

16 l (4.2 gallon US) - 5 l (1.3 gallon US)

Dry weight

189 kg (416.7 pounds)
