Year : 2008 , Category : Sport , Type : 1099 cc, liquid cooled, 90Â° l-twin, 4-stroke , Bore x stroke (mm) : 104 mm x 64.7 mm

Details:

Bimota DB7 2008 motorcycles specifications
read comments (-)	\|	add comments

Year

2008

Category

Sport

Type

1099 cc, liquid cooled, 90Â° l-twin, 4-stroke

Bore x stroke (mm)

104 mm x 64.7 mm

Compression ratio

12.5:1

Valves

Desmodromic, 4 valves per cylinder

Fuel system

Magneti Marelli fuel injection 60 mm throttle body

Ignition

Power

160 hp (119.3 kW) @ 9750 rpm

Torque

122 Nm (90 ft. lbs) @ 8000 rpm

Lubrication system

Wet sump

Clutch

Dry clutch multi-disc with hydraulic actuation system

Gearbox

6 speed

Ratios

1e 24/23, 2nd 23/24, 3th 22/26, 4th 20/28, 5th 17/30, 6th 15/37

Primary drive

32/59

Final drive

Chain, 15/38

Starting system

Electronic

Frame

Front suspension

43 mm Marzocchi UD fork DLC fully adjustable, 120 mm travel

Rear suspension

Extreme Tech Monoshock TTX fully adjustable, 120 mm travel

Rake / Traill

Wheels

Forged Al Alloy

Front whell

Rear whell

Front tyre

120/70-17

Back tyre

190/55-17

Front brakes

dual 320 mm discs with radial-mounted 4-piston calipers

Rear brakes

single 230 mm disc with 2-piston calipers

Overall length

2100 mm (82.7 inches)

Overall width

700 mm (27.6 inches)

Overall height

1115 mm (43.9 inches)

Seat height

800 mm (31.5 inches)

Wheelbase

1435 mm (56.5 inches)

Ground clearance

135 mm (5.3 inches)

Fuel capacity - reserve

16 l (4.2 gallon US)

Dry weight

170 kg (374.8 pounds)
