Daelim History 2005 motorcycles specifications

www.motorcyclesdetails.info

add to favorites

Year : 2005 , Category : Scooter , Type : 124.9 cc, oil/air cooled, single cylinder, 4-stroke , Bore x stroke (mm) : 56 mm x 50

Details:

Daelim History 2005 motorcycles specifications
read comments (-)	\|	add comments

Year

2005

Category

Scooter

Type

124.9 cc, oil/air cooled, single cylinder, 4-stroke

Bore x stroke (mm)

56 mm x 50.7 mm

Compression ratio

11:1

Valves

OHC, 2 valves per cylinder

Fuel system

Ignition

CDI

Power

12.5 hp (9.3 kW) @ 9500 rpm

Torque

10.4 Nm (7.7 ft. lbs) @ 7400 rpm

Lubrication system

Clutch

Gearbox

1, automatic convertor

Ratios

Primary drive

Final drive

V-belt

Starting system

Electronic & Kick

Frame

Front suspension

Telescopic fork

Rear suspension

Swing arm

Rake / Traill

Wheels

Front whell

Rear whell

Front tyre

120/70-12

Back tyre

130/70-12

Front brakes

single 220 mm disc with 2-piston calipers

Rear brakes

single 200 mm disc with 1-piston calipers

Overall length

1960 mm (77.2 inches)

Overall width

703 mm (27.7 inches)

Overall height

1224 mm (48.2 inches)

Seat height

775 mm (30.5 inches)

Wheelbase

1347 mm (53 inches)

Ground clearance

110 mm (4.3 inches)

Fuel capacity - reserve

8.5 l (2.2 gallon US)

Dry weight

123 kg (271.2 pounds)
