Year : 2007 , Category : All-road , Type : 124.2 cc, liquid cooled, single cylinder, 4-stroke , Bore x stroke (mm) : 58 mm x 47

Details:

Derbi Mulhacen 125 2007 motorcycles specifications
read comments (-)	\|	add comments

Year

2007

Category

All-road

Type

124.2 cc, liquid cooled, single cylinder, 4-stroke

Bore x stroke (mm)

58 mm x 47 mm

Compression ratio

12:1

Valves

Dohc, 4 valves per cylinder

Fuel system

Carburettor 30mm

Ignition

Power

15 hp (11.2 kW) @ 9500 rpm

Torque

Lubrication system

Dry sump with integrated oil deposit

Clutch

Multi-plate in oil bath

Gearbox

6 speed

Ratios

Primary drive

Final drive

Chain

Starting system

Electronic

Frame

Tubular High Tensile Steel

Front suspension

37mm hydraulic fork, 130 mm travel

Rear suspension

Mono-shock, 130 mm travel

Rake / Traill

Wheels

Front whell

Rear whell

Front tyre

100/90-18

Back tyre

130/80-17

Front brakes

single 280 mm disc with 2-piston calipers

Rear brakes

single 220 mm disc with 1-piston calipers

Overall length

1976 mm (77.8 inches)

Overall width

750 mm (29.5 inches)

Overall height

1065 mm (41.9 inches)

Seat height

790 mm (31.1 inches)

Wheelbase

1326 mm (52.2 inches)

Ground clearance

Fuel capacity - reserve

11 l (2.9 gallon US)

Dry weight

110 kg (242.5 pounds)
