Honda CB 1300 S 2008 motorcycles specifications

www.motorcyclesdetails.info

add to favorites

Year : 2008 , Category : Sport touring , Type : 1284 cc, liquid cooled, 4 - cylinders in line, 4-stroke , Bore x stroke (mm) :

Details:

Honda CB 1300 S 2008 motorcycles specifications
read comments (-)	\|	add comments

Year

2008

Category

Sport touring

Type

1284 cc, liquid cooled, 4 - cylinders in line, 4-stroke

Bore x stroke (mm)

78 mm x 67.2 mm

Compression ratio

9.6:1

Valves

DOHC, 4 valves per cylinder

Fuel system

PGM-FI electronic fuel injection

Ignition

Computer-controlled digital transistorised with electronic advance

Power

114 hp (85 kW) @ 7500 rpm

Torque

117 Nm (86.3 ft. lbs) @ 5500 rpm

Lubrication system

Clutch

Gearbox

5 speed

Ratios

1e 3.083 (37/12), 2nd 2.062 (33/16), 3th 1.545 (34/22), 4th 1.272 (28/22), 5th 1.130 (26/23)

Primary drive

1.652 (76/46)

Final drive

Chain, 2.166 (39/18)

Starting system

Electronic

Frame

Front suspension

43 mm cartridge-type telescopic fork with adjustable compression and rebound damping, 109 mm travel

Rear suspension

Dual conventional dampers with 5-step adjustable spring preload, 116 mm travel

Rake / Traill

Wheels

U-section 5-spoke cast aluminium

Front whell

Rear whell

Front tyre

120/70-17

Back tyre

180/55-17

Front brakes

dual 310 mm discs with 4-piston calipers with Anti-Lock Braking System

Rear brakes

single 256 mm disc with 2-piston calipers with Anti-Lock Braking System

Overall length

2220 mm (87.4 inches)

Overall width

790 mm (31.1 inches)

Overall height

1120 mm (44.1 inches)

Seat height

790 mm (31.1 inches)

Wheelbase

1515 mm (59.6 inches)

Ground clearance

135 mm (5.3 inches)

Fuel capacity - reserve

21 l (5.5 gallon US) - 4 l (1.1 gallon US)

Dry weight

236 kg (520.3 pounds)
