Honda VT 750 Shadow 2008 motorcycles specifications

www.motorcyclesdetails.info

add to favorites

Year : 2008 , Category : Cruiser , Type : 745 cc, liquid cooled, 52Â° v-twin, 4-stroke , Bore x stroke (mm) : 79 mm x 76 mm

Details:

Honda VT 750 Shadow 2008 motorcycles specifications
read comments (-)	\|	add comments

Year

2008

Category

Cruiser

Type

745 cc, liquid cooled, 52Â° v-twin, 4-stroke

Bore x stroke (mm)

79 mm x 76 mm

Compression ratio

9.6:1

Valves

SOHC, 3 valves per cylinder

Fuel system

PGM-FI electronic fuel injection with automatic choke

Ignition

Fully transistorised electronic

Power

45 hp (33.6 kW) @ 5500 rpm

Torque

64 Nm (47.2 ft. lbs) @ 3500 rpm

Lubrication system

Clutch

Wet multi-plate type

Gearbox

5 speed

Ratios

Primary drive

Final drive

Cardan

Starting system

Electronic

Frame

Front suspension

41mm telescopic fork, 116 mm travel

Rear suspension

Dual conventional dampers with 5-step adjustable spring preload, 90 mm travel

Rake / Traill

Wheels

steel rim/wire spoke

Front whell

Rear whell

Front tyre

120/90-17

Back tyre

160/80-15

Front brakes

single 296 mm disc with 2-piston calipers

Rear brakes

180 mm drum

Overall length

2510 mm (98.8 inches)

Overall width

920 mm (36.2 inches)

Overall height

1125 mm (44.3 inches)

Seat height

658 mm (25.9 inches)

Wheelbase

1640 mm (64.6 inches)

Ground clearance

130.8 mm (5.1 inches)

Fuel capacity - reserve

14 l (3.7 gallon US) - 3.5 l (0.9 gallon US)

Dry weight

256.3 kg (565 pounds)
