Moto Morini Corsaro Avio 2008 motorcycles specifications

www.motorcyclesdetails.info

Moto Morini Corsaro Avio 2008 motorcycles specifications

add to favorites

Year : 2008 , Category : Naked bike , Type : 1187 cc, liquid cooled, 87Â° v-twin, 4-stroke , Bore x stroke (mm) : 107 mm x 66 m

Details:

Moto Morini Corsaro Avio 2008 motorcycles specifications
read comments (-)	\|	add comments

Year

2008

Category

Naked bike

Type

1187 cc, liquid cooled, 87Â° v-twin, 4-stroke

Bore x stroke (mm)

107 mm x 66 mm

Compression ratio

12.5:1

Valves

DOHC, 4 valves per cylinder

Fuel system

Magneti Marelli fuel injection 54 mm throttle body

Ignition

I.A.W. electronic

Power

120 hp (89.5 kW) @ 8500 rpm

Torque

102 Nm (75.2 ft. lbs) @ 6700 rpm

Lubrication system

Forced with trochoidal pump

Clutch

Wet, multiplate type

Gearbox

6 speed

Ratios

1e 13/36, 2nd 17/32, 3th 20/30, 4th 22/28, 5th 23/26, 6th 24/25

Primary drive

Spur gears 55:31

Final drive

Chain, 17/40

Starting system

Electronic

Frame

Verlicchi high-strength steel tube trellis frame

Front suspension

Marzocchi upside-down fork with 50 mm / 1,96 inch Ã˜ legs, adjustable in rebound, compression and spring preloading, 129 mm travel

Rear suspension

Progressive linkage with Sachs monoshock adjustable in rebound, compression and spring loading , 130 mm travel

Rake / Traill

-

Wheels

Brembo in light alloy 6 spokes

Front whell

-

Rear whell

-

Front tyre

120/70-17

Back tyre

180/55-17

Front brakes

dual 320 mm discs with 4-piston calipers

Rear brakes

single 220 mm disc with 2-piston calipers

Overall length

2070 mm (81.5 inches)

Overall width

810 mm (31.9 inches)

Overall height

-

Seat height

830 mm (32.7 inches)

Wheelbase

1440 mm (56.7 inches)

Ground clearance

140 mm (5.5 inches)

Fuel capacity - reserve

18 l (4.8 gallon US) - 3 l (0.8 gallon US)

Dry weight

198 kg (436.5 pounds)
