Voxan CafÃ© Racer 1000 V2 2006 motorcycles specifications

www.motorcyclesdetails.info

add to favorites

Year : 2006 , Category : Sport , Type : 996 cc, liquid cooled, v-twin, 4-stroke , Bore x stroke (mm) : 98 mm x 66 mm , C

Details:

Voxan CafÃ© Racer 1000 V2 2006 motorcycles specifications
read comments (-)	\|	add comments

Year

2006

Category

Sport

Type

996 cc, liquid cooled, v-twin, 4-stroke

Bore x stroke (mm)

98 mm x 66 mm

Compression ratio

10.5:1

Valves

DOHC, 4 valves per cylinder

Fuel system

Electronic fuel injection by Magnetti Marelli

Ignition

Electronic

Power

100 hp (74.6 kW) @ 9000 rpm

Torque

103 Nm (76 ft. lbs) @ 6500 rpm

Lubrication system

With oil by dry casing, oil tank in the body

Clutch

Multidisk oil with hydraulic control

Gearbox

6 speed

Ratios

1e 15/41 2,733 38, 2nd 19/39 2,053 50,6, 3th 21/34 1,619 63,4, 4th 24/32 1,333 76,4, 5th 26/30 1,154 89,1, 6th 28/29 1,036 100

Primary drive

1.1811 (37/67)

Final drive

Chain, 18*39

Starting system

Electronic

Frame

Double tube - Front and back molded and assembled with screws

Front suspension

Paioli inverted fork -Ã˜ 41 mm;hydraulic and adjustable compression. , 120 mm travel

Rear suspension

Adjustable Paioli shocks - Aluminium arms, 120 mm travel

Rake / Traill

Wheels

Front whell

Rear whell

Front tyre

120/70-17

Back tyre

180/55-17

Front brakes

dual 320 mm discs with 2-piston calipers

Rear brakes

single 245 mm disc with 2-piston calipers

Overall length

2100 mm (82.7 inches)

Overall width

740 mm (29.1 inches)

Overall height

Seat height

810 mm (31.9 inches)

Wheelbase

1435 mm (56.5 inches)

Ground clearance

Fuel capacity - reserve

18.5 l (4.9 gallon US) - 4 l (1.1 gallon US)

Dry weight

185 kg (407.9 pounds)
